Operating speed:1mm~1m/s
Operating frequency:Mechanical: 120 operations/minute
Electrical: 20 operations/minute
Contact resistance:200mΩ max.(Initial value with 3m cable)
Insulation resistance:100mΩ min.(at DC500V)
Conventional thermal current:5A
Electric parameter:AC250V/1A DC220V/0.3A
Dielectric strength:1890VAC, 50/60Hz 1min between terminals of the same polarity
2500VAC, 50/60Hz 1min between each terminal and non-current-carrying metal parts
2500VAC, 50/60Hz 1min between current-carrying metal parts and ground
Vibration resistance:Malfunction: 10Hz~55Hz, 1.5mm double amplitude
Shock resistance:Destruction: 500m/S² Malfunction: 200m/S²
Ambient temperature:-10℃~+70℃ with no icing
Ambient humidity:90% max.
Life expectancy:Mechanical: 10,000,000 operations min.
Electrical: 100 000 operations min.
Degree of protection:IP67
