Payment & Shipping Terms:
|Contact Load:||Low Power|
|Rated load||10A/240VAC 28VDC||16A/240VAC 28VDC||5A/240VAC 28VDC|
|Operate voltage (23℃)||DC:≤75%*Rated voltage|
|Release voltage (23℃)||DC:≥10%*Rated voltage|
|Maximum voltage (23℃)||110%*Rated voltage|
|Normal coil voltage||DC||3-11OV|
|Normal coil power||DC||0.53W|
|Dielectric strength||Between Same-pole contacts||1000VAC/1min(leakage current 1mA)|
|Between Opposite-pole contacts|
|Between contacts and coil||5000VAC/1min(leakage current 1mA)|
|Ambient temperature||-55℃ ~70℃|
|Shock resistance||10G (sinusoidal half-wave pulse: 11ms)|
|Vibration resistance||10-55Hz (double amplitude: 1.5mm)|
1.How do you control the quality?
100% Auto inspection machine and manul testing together before packing.
2.What's your payment terms?
We usual accept 30% T/T payment in advance, and the balance payment before shipment,
Samples cost can be paid by west union ,because it's fast and convient.
3.Would you accept to USE our LOGO?
If you have good quality,we can make OEM and ODM,custiomized specification.
4.Can I get a sample for reference?
we are gald to send samples for your testing, but you need to pay the express cost.
5.What is your delivery time?
Usually, 1-3days for samples, 10-20 days for bulk goods.
6.What is your warranty time of the products?
One year from the shipment date,we will offer replacement if you receive the defective or wrong items.
