power relay HHC71G1(JQX-58F)

China power relay HHC71G1(JQX-58F) supplier
power relay HHC71G1(JQX-58F) supplier power relay HHC71G1(JQX-58F) supplier

Large Image :  power relay HHC71G1(JQX-58F)

Product Details:

Place of Origin: China
Brand Name: clion
Model Number: HHC71G1(JQX-58F)
Contact Now
Detailed Product Description

https://clion.en.alibaba.com/product/60631897674-804346879/NNC_Power_Relay_HHC71G1_58F.html?spm=a2700.8304367.0.0.apWA4W
Product Overview

Part NO.
HHC71G1(JQX-58F)
Dimension
68*47*60
Contact Feature
Form
1A,1B,1C
Rated load
60A
Max switching voltage
250VAC/28VDC
Contact resistance
≤100mΩ
Material
Silver Alloy
Electrical life
≥1*105
Mechanical life
≥1*107
Operate voltage (25℃)
DC:≤75%*Rated voltage
AC:≤80%*Rated voltage
Release voltage (25℃)
DC:≥10%*Rated voltage
AC:≥30%*Rated voltage
Maximum voltage (25℃)
110%*Rated voltage
Normal coil voltage
DC
6-220V
AC
6-380V
Normal coil power
DC
2.0W
AC
8.6VA
Pick-up time(Rated voltage)
≤25ms
Release time(Rated voltage)
≤15ms
Dielectric strength
Between Same-pole contacts
1500VAC/1min(leakage current 1mA)
Between Opposite-pole contacts
1500VAC/1min(leakage current 1mA)
Between contacts and coil
2500VAC/1min(leakage current 1mA)
Insulation resistance
≥500mΩ(500VDC)
Ambient temperature
-25℃ ~55℃
Ambient humidity
45%-75%RH
Atmospheric pressure
86-106KPa
Shock resistance
10G (sinusoidal half-wave pulse: 11ms)
Vibration resistance
10-55Hz (double amplitude: 1.0mm)
Installation
SCREW
Packing
Inner box
Paper box(pcs)
/
Foam box(pcs)
10
Outer box
Paper box(pcs)
/
Foam box(pcs)
100
Dimension of the carton
Paper box(pcs)
/
Foam box(pcs)
402*288*370MM
Weight
1PC
Approximate 170g
1CTN
G.W:18KG N.W:17KG
