NNC miniature PCB electric Relay NNC69KTL -1Z JQX-14FT 1C 10A DC 3V-24v voltage 5pin socket mounting relay, UL approval

Good quality solid state relay for sales
Good quality solid state relay for sales
We prefer good quality solid state relay , Clion is a strong supplier, they have big factory and advanced equipment ,

—— Mr Sergey

The wonderful big power relay fits our motor, they work well , we have cooperated with each other for many years, Clion is a good supplier.

—— Mr Edward

We are wholesaler, we have large quantity order of miniature PCB relay and general purpose electromagnetic relay from Clion, they sell well .

—— Mr King

I'm Online Chat Now

NNC miniature PCB electric Relay NNC69KTL -1Z JQX-14FT 1C 10A DC 3V-24v voltage 5pin socket mounting relay, UL approval

China NNC miniature PCB electric Relay NNC69KTL -1Z JQX-14FT 1C 10A DC 3V-24v voltage 5pin socket mounting relay, UL approval supplier

Large Image :  NNC miniature PCB electric Relay NNC69KTL -1Z JQX-14FT 1C 10A DC 3V-24v voltage 5pin socket mounting relay, UL approval

Product Details:

Place of Origin: CHINA
Brand Name: NNC
Certification: CE,UL ,CQC
Model Number: NNC69KTL

Payment & Shipping Terms:

Minimum Order Quantity: 1000 pcs
Price: get the latest price
Packaging Details: export packing
Delivery Time: 5-10days
Supply Ability: 100000/Per month
Detailed Product Description
Product Name: Mini Electromagnetic Relay Color: White

https://www.alibaba.com/product-detail/NNC-miniature-PCB-electric-Relay-NNC69KTL_60668669951.html?spm=a2747.manage.list.52.BPLyUq

Detailed Images

Related Products


Product Description

 Model Description

69K 1.png



Specification

Part NO. NNC69KTL(JQX-14FTL)
Dimension 28.8*12.7*34
Contact Feature Form 1A,1B,1C 2A,2B,2C
Rated load NC 12A/240VAC 28VDC NO 15A/240VAC 28VDC 8A/240VAC 28VDC
Contact resistance ≤100mΩ
Material Silver Alloy
Electrical life ≥1*105
Mechanical life ≥1*107
Operate voltage (23℃) DC:≤75%*Rated voltage
AC:≤80%*Rated voltage
Release voltage (23℃) DC:≥10%*Rated voltage
AC:≥30%*Rated voltage
Maximum voltage (23℃) 110%*Rated voltage
Normal coil voltage DC 3-11OV
AC 6-220V
Normal coil power DC 0.53W
AC 1.0VA
Pick-up time ≤20ms
Release time ≤10ms
Dielectric strength Between Same-pole contacts 1000VAC/1min(leakage current 1mA)
Between Opposite-pole contacts
Between contacts and coil 5000VAC/1min(leakage current 1mA)
Insulation resistance ≥100mΩ(500VDC)
Ambient temperature -55℃ ~70℃
Ambient humidity 35%-80%RH
Atmospheric pressure 86-106KPa
Shock resistance 10G (sinusoidal half-wave pulse: 11ms)
Vibration resistance 10-55Hz (double amplitude: 1.5mm)
Installation PCB,Socket
